Standard Features

• Sealed Gearbox: Ensures even lubrication for smooth operation.
• Sealed Drive Shaft and Encased Bearing: Prevents oil contamination and ensures longevity.
• Extended Output Shaft: 3-1/4" x 3/4" shaft fits a broad range of tarping systems.
• 90 Tooth Drive Gear: Provides more torque and extended life.
• Flexible Mounting: Five mounting holes designed to fit three and four-bolt configurations.
• Quality Control: 100% tested for reliability and performance.
• Safety Feature: Shaft in the motor will not turn without an electric current.
• Chrome Motor Cover: Adds durability and a polished finish.
• Warranty: Includes a 5-year warranty (note: opening, separating, or tampering with the motor and gearbox will void the warranty).

Specifications

• Voltage: 12V
• Power: 2HP
• Gear Ratio: 90:1
• Wattage: 1200 Watts
• Gear Reduction: Worm to wheel
• Mounting: Three 5/16"-18 bolts
• Operating Torque: 36.90 lbs
• Operating Speed: 50 RPM

Contact Us

For more information or to place an order, contact our sales associates at 800-532-TARP. Trust Austin Tarp & Cargo Controls® for high-quality and reliable dump truck tarp motors.

Phone: 800-532-TARP

Address: 2901 Stewart Creek Blvd., Charlotte, NC 28216
